Solar Photovoltaics

Get your electricity from sunlight!

How it works

The photoelectric effect is when photons knock electrons off of atoms. Einstein received his Nobel Prize for describing this phenomenon which is at the heart of the operation of a solar panel. The simple explanation of solar power is that energy from light knocks electrons out of place in the solar panels, which then flow through your house, providing electricity.
Before getting into anything more complicated than that it should be clear that the operation of a solar power system is incredibly simple as there is essentially no operation at all. A solar array will silently and reliably provide power to your house and you will absolutely not notice any difference. As far as maintenance goes, a well installed system should require nothing from the owner other than keep the panels relatively clean and free of debris or shading.
Ok, now on to the science. Solar panels that provide electricity are called Photovoltaic (PV) panels. Conventional PV panels are made from silicon, wires, and the framing. Conductors, such as wires, have some electrons which aren't very strongly attached to the atoms and they move around from atom to atom fairly easily. Insulators, such as plastic, don't have loose electrons and they are used to cover wires to protect people from getting shocked.
Silicon is a semi-conductor. In its pure form it is not a good conductor at all but its atomic structure is such that by adding a tiny bit of an impurity you can make it a conductor. In fact, pure silicon has about 30,000 times more resistance than it does when you add amounts of impurities as small as a few parts per million. When you add a tiny bit of phosphorous to the silicon you get a material that has some loosely attached electrons. These electrons aren't exactly extra, but this material is called "N-type" silicon for having extra electrons which, by convention, have a negative charge. If you add a tiny amount of boron to silicon you get a material which has space for extra electrons. These spaces allow electrons to flow through the material and because of the 'lack' of electrons, which are negatively charged, this material is call "P-type" silicon for positive.


Atomic Orbitals

To get a little deeper into the behavior of silicon you need to go into how electrons arrange themselves in an atom. Electrons like to arrange themselves into orbitals. The mechanics behind why they do this has to do with the wave properties of matter and getting into that is going a little too far here. Basically, electrons are only allowed to have certain energies in their orbits and certain patterns of orbits have less energy than others. When the electrons fit into a nice pattern it takes more energy to free up an electron than when they don't.
The orbitals for the smaller atoms (Silicon is relatively small) have orbitals called s or p and the first s and p orbitals are arranged like 1s 2s 2p 3s 3p where each number corresponds to a shell. When an atom has a full shell it is really happy. Too happy. Atoms where the electrons make full shells are very inert and will not react much with other atoms so they are difficult to manipulate. Each s orbital holds up to 2 electrons. Each p orbital consists of three sub-orbitals that hold 2 electrons each, for a total of 6 electrons and electrons per p orbital. A neutral silicon atom has 14 electrons. This gives silicon full 1s and 2s orbitals and then a full 2p orbital, with four electrons left over.
The electrons in the full shells are called "core electrons" because they don't interact with anything outside of their silicon atom. The left over electrons don't organize themselves so neatly. The 3s and 3p orbitals rearrange themselves to form four sp3 hybrid orbitals of equal energy, each containing a single electron. Since these electrons are not in complete shells, they can react with electrons in the incomplete outer shells of other atoms to form bonds. These electrons that are available to form bonds with other atoms are called valence electrons.
Electrons don't just interact with the nucleus that they are orbiting. They interact with the electrons of other atoms around them. This is how atoms bond together and materials like silicon form crystals. Silicon has four valence electrons. Two valence electrons from different atoms can pair up and form a strong bond which is called a covalent bond. Having four valence electrons an atom of silicon is able to bond with four other atoms of silicon and form a nice strong crystal. The entire crystal is made up of bonded atoms of silicon, each atom bound to four others around it.
Phosphorous has one more electron than silicon does. Because of this, phosphorous is able to fit pretty nicely into a silicon crystal, except that it has five valence electrons instead of four, leaving one extra electron that doesn't fit well into the silicon crystal structure, which prefers to have four valence electrons for every atom. This makes the extra electron a "hot potato" of sorts within the crystal. It's not that it will fly off for no reason, since the charges between protons and electrons are still balanced, but it doesn't take a lot to free that electron, and that makes phosphorous doped silicon something that can conduct electricity.
Boron has five electrons. The two in the 1s orbital form the core, and the 2s and 2p orbitals contain three valence electrons. If a boron atom is in the middle of a bunch of silicon atoms it tries to join in the arrangement where four electrons are shared, but it is one electron short. Because of this there is what is called a "hole" for an electron where a boron atom sits inside a silicon crystal. These holes make a path for electrons to travel (hopping from hole to hole) and allow the material to conduct electricity.


PV comes together

When you take a thin slice of N-type silicon (free electrons) and slap it onto a thin slice of P-type silicon (wants electrons) and you do something to kick loose some electrons (the photoelectric effect), you get a situation that can provide power. Free electrons will want to hang out more on the P side than they will on the N side. The number of protons on either side doesn't change, so you end up with the N side having a net positive charge (electrons are negative) and the P side having a net negative charge. The separation of charges creates an electric field. The continued exposure to light keeps knocking electrons loose and the electric field exerts a force on the electrons. If you give the electrons a path (an electrical circuit) they will flow away from the negatively charged area and towards the positively charged area. The electrons will be able to overcome some resistance on this path and that means they can do work, like light up a light bulb.
